What is quality management (QM) in manufacturing?
Quality management (QM) is the systematic approach to ensuring that products consistently meet defined requirements — customer specifications, regulatory standards, and internal targets. ISO 9000:2015 defines QM as "management with regard to quality," encompassing four activities: quality planning (setting quality objectives and defining processes), quality control (fulfilling quality requirements during production), quality assurance (providing confidence that requirements are met), and quality improvement (increasing the ability to meet requirements). In discrete manufacturing, QM is not an abstract management framework — it is the daily work of preventing defects, detecting deviations, and improving processes. The structural backbone of QM is the ISO 9001 standard, which organises the entire quality management system around the PDCA cycle.
The data backbone — the thing that makes QM measurable rather than aspirational — is the MES. An MES captures what actually happens on the shopfloor: how many good parts, how many rejects, which defect types, which process parameters drifted, on which machine, during which shift. Without this data, QM operates on estimates and delayed reports. With it, QM operates on facts and real-time feedback.
What is the difference between QM, QC, and QA?
These three terms are used interchangeably in everyday language — but they describe different things at different levels. Getting the distinction right matters, because each maps to different activities, different tools, and different data sources:
| Dimension | Quality Management (QM) | Quality Assurance (QA) | Quality Control (QC) |
|---|---|---|---|
| ISO 9000 definition | Management with regard to quality — the overarching system that includes QA, QC, planning, and improvement. | Part of QM focused on providing confidence that quality requirements will be fulfilled. | Part of QM focused on fulfilling quality requirements — the operational act of checking and correcting. |
| Focus | System-level: policies, objectives, processes, responsibilities, continuous improvement. | Process-level: are the processes designed so that they produce conforming output? Preventive orientation. | Product-level: does this specific part meet the specification? Detective orientation. |
| When it acts | Continuously — strategic planning, management review, audits, CI initiatives. | Before and during production — process validation, FMEA, control plans, Poka Yoke. | During and after production — in-process inspection, end-of-line testing, incoming goods inspection. |
| Typical tools | ISO 9001 QMS, IATF 16949, management reviews, internal audits, KPI dashboards. | FMEA, control plans, process capability studies (Cpk), MSA, SPC setup, Poka Yoke design. | Gauges, CMMs, vision systems, go/no-go fixtures, SPC charts, sampling plans. |
| MES role | MES provides the data infrastructure for the entire QMS: OEE Quality rate, PPM tracking, process data history, traceability. | MES enforces QA through digital Poka Yoke, routing enforcement, and process parameter monitoring. | MES records QC results (good/reject counts, defect classification) and links them to machine, order, shift, and timestamp. |
The practical implication: a plant that only does QC (inspecting parts) but has no QA (preventing defects through process design) will always be reactive. A plant that has QA but no QM system (no structured improvement cycle, no management review, no audit) will improve sporadically but not sustainably. QM is the system that connects QA and QC into a coherent, improving whole — and the MES is the data layer that makes all three measurable.
How is ISO 9001 structured — and where does MES data fit?
ISO 9001:2015 is explicitly built on the PDCA cycle. Each clause maps to a phase of the cycle. For manufacturing companies, the MES provides the operational data that feeds multiple clauses:
| Clause | ISO 9001 topic | PDCA phase | What it requires | MES contribution |
|---|---|---|---|---|
| 4 | Context of the organisation | — | Understand internal and external factors, interested parties, scope of the QMS. | MES data reveals the actual production context: which processes are stable, which are volatile, where the biggest quality losses occur. |
| 6 | Planning | Plan | Set quality objectives, plan actions to address risks and opportunities. | MES quality data (PPM trends, scrap Pareto, defect types) informs which quality objectives to set and which risks to address first. |
| 8 | Operation | Do | Control production processes, ensure product conformity, manage nonconforming output. | MES enforces process control in real time: process parameter monitoring, routing enforcement, automatic reject classification. At Neoperl, SPS alarm correlation reduced scrap by 15 % — a direct clause 8 outcome. |
| 9 | Performance evaluation | Check | Monitor, measure, analyse, and evaluate QMS performance. Conduct internal audits and management reviews. | MES provides the clause 9 data automatically: OEE Quality rate, PPM per product/machine/shift, process capability trends, nonconformity rates. At Meleghy, this data feeds management reviews across 6 plants. |
| 10 | Improvement | Act | Determine opportunities for improvement, implement corrective actions, continually improve the QMS. | MES data triggers and verifies improvements: the Pareto identifies the top loss, the before/after comparison proves whether the corrective action worked. This is PDCA powered by production data. |
What are the 7 basic quality tools — and which ones use MES data?
Kaoru Ishikawa defined the 7 basic QM tools in the 1960s — simple enough for every shopfloor worker to use, powerful enough to solve 95 % of quality problems. In a modern MES-equipped plant, most of them are generated automatically:
| # | Tool | What it does | MES data source | Example |
|---|---|---|---|---|
| 1 | Cause-and-effect diagram (Ishikawa / Fishbone) | Structures brainstorming about root causes into categories (Man, Machine, Material, Method, Measurement, Environment). | MES does not generate the diagram, but provides the data that makes the brainstorm fact-based: which machine, which shift, which material batch, which process parameters were active when the defect occurred. | Scrap rate spikes on CNC-12. MES shows: only on night shift, only with material batch #4712, only when spindle speed > 8,000 RPM. The Ishikawa session starts with facts, not guesses. |
| 2 | Check sheet | Structured form for collecting data consistently (defect type, frequency, location). | MES replaces the paper check sheet: operators classify rejects by defect type at the station (touchscreen input). Data is digital, timestamped, and immediately available for analysis. | Instead of paper tally marks, the operator taps "burr," "dimensional," or "surface" on the MES terminal. The data feeds the Pareto automatically. |
| 3 | Pareto chart | Ranks defect types by frequency or impact. Identifies the vital few (80/20 rule). | MES generates the Pareto automatically from reject data: by defect type, by machine, by product, by shift. The SYMESTIC production metrics module provides this as a standard dashboard. | "Burr" accounts for 42 % of all rejects on the press line. That is the first PDCA cycle. No discussion needed — the data decides the priority. |
| 4 | Histogram | Shows the distribution of a measured variable (e.g., part dimension, cycle time). Reveals whether the process is centred, skewed, or bimodal. | MES process data module captures the measurements per cycle. Histogram is generated from the stored data. | Press force histogram shows a bimodal distribution — two peaks instead of one. Root cause: two different tool inserts with slightly different geometry. Without the histogram, nobody would have noticed. |
| 5 | Control chart (SPC) | Monitors a process parameter over time with control limits (UCL/LCL). Distinguishes common cause variation from special cause variation. | MES captures the process parameter per cycle (temperature, force, time) and plots it against control limits. Alarms fire when a point exceeds the limits or when a pattern (run, trend) indicates drift. | At Neoperl, SPS alarm correlation is a form of control charting: monitoring process parameters in real time and detecting the patterns that precede defects — before the defects occur. |
| 6 | Scatter diagram | Shows the relationship between two variables (e.g., does higher temperature correlate with more defects?). | MES provides both variables with timestamp: process parameter X and quality outcome Y per cycle. The correlation can be analysed from the exported data. | Scatter plot of hydraulic pressure vs. reject rate. Clear positive correlation above 280 bar. New process limit set at 275 bar. Reject rate drops by 30 %. |
| 7 | Stratification | Separates data into meaningful subgroups (by machine, shift, operator, material, product) to reveal patterns hidden in aggregated data. | MES records every event with all context dimensions: machine, shift, order, product, operator. Stratification is a standard filter operation on the MES dashboard — select machine, compare shifts. | Overall scrap rate: 2.1 %. Stratified by shift: day shift 1.4 %, night shift 3.2 %. The problem is not the process — the problem is on night shift. Completely different root cause investigation. |
What does QM look like in automotive (IATF 16949)?
For SYMESTIC's automotive customers (Meleghy, Carcoustics), QM is not optional — it is a contractual requirement. IATF 16949:2016 builds on ISO 9001 and adds automotive-specific requirements. The MES data connections are direct:
| IATF 16949 requirement | What it demands | How MES data supports it |
|---|---|---|
| Product traceability (8.5.2) | Ability to trace a finished product back to its raw materials, process steps, and process parameters. | MES links each unit (serial number or batch) to: machine, order, operator, timestamp, process parameters per cycle. At Meleghy, bidirectional SAP integration maps every machine cycle to the Fertigungsauftrag — full traceability from ERP order to shopfloor cycle. |
| Process capability (Cpk) (8.5.1.2) | Demonstrate that production processes are capable of consistently producing within specification. Cpk ≥ 1.33 for stable processes. | MES process data module captures the measurements that feed Cpk calculations. Continuous monitoring — not just initial capability study, but ongoing process surveillance. |
| Control of nonconforming output (8.7) | Identify, segregate, and disposition nonconforming products. Prevent unintended use or delivery. | MES flags reject parts in real time, prevents them from advancing to the next station (digital Poka Yoke), and records the disposition (scrap, rework, concession) with full audit trail. |
| Reaction plan for out-of-control (8.5.1.1) | Defined escalation when a process goes out of control (SPC alarm, process parameter exceedance). | MES alarms module triggers the escalation automatically. At Neoperl, SPS alarm patterns are the out-of-control trigger that initiates the reaction plan — without waiting for a human to notice. |
| PPM monitoring (9.1.2) | Monitor customer satisfaction through delivery quality metrics (PPM). | MES provides internal PPM in real time. At Meleghy, bidirectional CASQ-it integration connects internal quality data to the CAQ system for external PPM reporting. |
FAQ
Is an MES a QM system?
No. An MES is not a QM system and does not replace ISO 9001 certification, document management, audit scheduling, or CAPA (Corrective and Preventive Action) tracking. Those are the domain of dedicated QMS software (e.g., Babtec, iqs, CAQ AG, BaanQMS) or the quality module of an ERP system. What the MES does is provide the real-time production data that the QM system needs to function: good/reject counts, process parameters, downtime reasons, traceability records. The MES is the data source; the QMS is the management system that acts on the data. At Meleghy, the bidirectional CASQ-it integration connects SYMESTIC (MES) to Böhme & Weihs (CAQ) — exactly this separation of data capture and quality management.
What is the relationship between QM and OEE?
OEE has three components: Availability × Performance × Quality. The Quality factor of OEE = Good parts ÷ Total parts produced. This is the direct connection: the OEE Quality rate is the most basic QM metric for any production line. A plant with 99.8 % Quality rate is producing at 2,000 PPM internal. A plant with 99.5 % Quality rate is producing at 5,000 PPM. The MES calculates both — OEE Quality and PPM — from the same data: cycle counts of good and reject parts per machine, per order, per shift.
How does QM differ from Six Sigma?
QM is the management system — the policies, processes, and structures that govern quality in an organisation. Six Sigma is a specific improvement methodology that uses statistical tools (DMAIC, DOE, hypothesis testing) to reduce process variation and defects. Six Sigma operates within the QM system: it is one of the methods used to fulfil the "continual improvement" requirement of ISO 9001 clause 10. A company can have a QM system without Six Sigma (using PDCA and Kaizen instead). But a company running Six Sigma projects without a QM system will struggle to standardise and sustain the improvements.
What QM data should a manufacturing plant track as a minimum?
Five metrics form the QM data backbone for any discrete manufacturing plant: (1) Internal PPM per machine, product, shift — the most basic quality metric. (2) Defect type Pareto — which defect types account for the most rejects. (3) First Pass Yield (FPY) — what percentage of parts pass inspection on the first attempt, without rework. (4) Scrap cost per period — translating quality losses into financial impact. (5) Process capability (Cpk) for critical-to-quality parameters — the leading indicator that predicts future PPM. The MES captures metrics 1–3 automatically. Metric 4 requires cost data from the ERP. Metric 5 requires the MES process data module for the measurement data and a statistical tool (or export) for the Cpk calculation.
